HP Switch(config)# int c5 speed-duplex auto-10-100 To configure port C5 for auto-10-100, enter this command: Only these speeds are allowed with this setting. The 10/100 auto-negotiation feature allows a port to establish a link with a port at the other end at either 10 Mbps or 100 Mbps, using the highest mutual speed and duplex mode available. Specifies the port's data transfer speed and mode. Note that in the above Syntax:, you can substitute int for interface (for example, int ). When you have finished making changes to the above parameters, press, then press (for Save).
The cursor moves to the Enabled field for the first port.įor further information on configuration options for these features, see the online help provided with this screen. Use arrow keys to change action selection and to execute + -Ĭancel changes and return to previous screen. Port Type Enabled Mode Flow Ctrl Group Type Switch Configuration - Port/Trunk Settings Port/trunk settings with a trunk group configured Gigabit Fiber-Optic Ports (Gigabit-SX, Gigabit-LX, and Gigabit-LH): Only these speeds are allowed with this setting.Īuto-1000: Uses 1000 Mbps and negotiates with the port at the other end of the link for other port operation features. (Cat 5 cabling is required for 100 Mbps links.).Īuto-100: Uses 100 Mbps and negotiates with the port at the other end of the link for other port operation features.Īuto-10-100: Allows the port to establish a link with the port at the other end at either 10 Mbps or 100 Mbps, using the highest mutual speed and duplex mode available. HP recommends auto-10 for links between 10/100 auto-sensing ports connected with Cat 3 cabling. Also negotiates flow control (enabled or disabled). MDIX: Sets the port to connect with a PC using a straight-through cable (manual mode-applies only to copper port switches using twisted-pair copper Ethernet cables)Īuto-10: Allows the port to negotiate between half-duplex (HDx) and full-duplex (FDx) while keeping speed at 10 Mbps. MDI: Sets the port to connect with a PC using a crossover cable (manual mode-applies only to copper port switches using twisted-pair copper Ethernet cables) Status and Counters in the menu interface. To see what the switch negotiates for the auto setting, use theCLI show interfaces brief command or the 3. Auto-MDIX (default): Senses speed and negotiates with the port at the other end of the link for port operation (MDI-X or MDI).
